Trailer Details

16ft x 6’6ft Race Car Trailer

4 Heavy Duty Chassis Rail’s with Open middle

Tare Weight 900kg

Red Powder Coated & Zinc Coated Adjustable Tire Rack

Aluminum Locking Bar with Tie-down Straps & Padlocks

1000mm High x 2100mm Wide Aluminum Stone Guard

Quick Lash System welded to floor with straps and Tie-bar

2 x Spring Lashing Rings at Rear

Steel Checker Plate Floor runners with Aluminum Drop-down floor

1960mm between guards only for 3.5ton trailers

Draw Bar and Support Bracing

3.5 Ton Rocker Roller Suspension

50mm Thick Axles

6 Stud Dexter Hubs, 12″ Electric Brakes on all 4 wheels

4 x 195r/ 15″ Black Sunraysia wheels

Cable Hand Brake

13mm Safety Chains

X-Bull 6000lbs Remote Control Electric Winch

Tapered checker-plate toolbox fitted to drawbar

The Winch Mount: Bolted down securely on a raised pedestal to clear the floor and give you a straight line for the synthetic rope

 The Power Supply: An Exide Powerider battery locked down tight with J-bolts and a heavy-duty hold-down clamp.

Safety & Connectivity: The isolation switch with the removable red key is perfectly placed for quick access, keeping the winch completely dead when not in use. Running it to the front-mounted Anderson plug makes connecting to the tow vehicle or an external charger seamless.

Top mount 1.8-meter Steel Ramps with T-handle Locking bolt.

Custom Made Checker-Plate Side Extension’s

Weld On Swing-Up 8″ Jockey wheel

L.E.D. Lights mount underneath Side Extension’s

1 Number plate light and 6 Reflectors

2 Side Marker Lights Below Centre of Guards

Painted in Industrial 2Pac Gloss Black

Compliance plate and Stamped Vin Number

Extras:

195r/ 15″ Spare wheel $150

2 Extra Lashing Rings fitted for Rear $125

QuickLash System added for Rear $1040

Victoria Registration Only $180
